Xinxiang Mengma Oil Filter is the abbreviated form of lubricating oil filter,it can be also called machine oil filter, inlet grid, Mengma oil filter can remove impurities which occur during air compressor is normal operated&remove rubber impurities which produced from unit heat and air oxidation.if directly pass machine oil including impurities into surface of moving parts, it will not only accelerate wear of parts, and also cause blockage of oil-way. So put oil filter into lube oil system is necessary, Mengma oil filter will make circulating machine oil clean before they come to surface of moving parts, to make sure friction surface is good lubricated, extending service life of air compressor. Normally, Mengma installation of oil filter is external rotary type, some are built-in type.

1.Filtering precision:10um--15um

2.Filtration efficiency:99.8%.

3.Service life is approximately 2000h -4000h

4.Filter element of oil filter is made by the thin fiberglass,which imported from HV&Ahistrom company.

Test Standard: Cracking Resistance Standard is accordance with ISO 2941

             Structural Ntegrity Standards is accordance with ISO 2942

             Material and liquid compatibility standards ISO 2943

End load test standard is in accordance with ISO3723

Filter element fatigue characteristic standard ISO3724

Differential pressure flow characteristic standard ISO3986

Multiple pass criteria for measuring filtration characteristics ISO4572
